Magswitch MLA1000X6 Heavy Duty Lifter is built for heavy-duty lifting, our magnet technology is powerful without the need for a power source. Safely lock in the on and off position with a 3:1 Safe Working Load of 2034 pounds. The dual lift hook offers the stability to lift horizontally and a single hook to lift into a vertical position.
Features & Benefits
- Magnetic field turns completely on and off mechanically.
- Magnet stays clean.
- Does not use an electrical power source.
- Lock On/Off handle.
- Superior hold force on Thin steel (70 mm deep field).
- Compact, lightweight and easy actuation.
- Lifts large flat sheets, beams, pipe.
- Performs well on air gaps such as rust and dirt.
- Customizable pole shoes to fit almost any application
- Fast, easy positioning
- More effective on thinner material than competitors
- An innovative breakthrough in magnetic technology that provides powerful control
- Will not overheat like electromagnets
- Locking handle
- Sheds debris
Quick Specs
- Max Breakaway: 6088 lbs (2761.4 kg) on 2” steel
- 3:1 Safe Working Load: 2034 lbs (922.6 kg)
- 2:1 Shear Working Load: 617 lbs (279.8 kg)
- Full Saturation Thickness: 1 in (25.4 mm)
- Minimum Thickness for De-Stack: 1 in (25.4 mm)
- Product Weight: 60.3 lbs (27.3 kg)
- Mounting Thread: M8x1.25
- Dimensions: 20.1 x 7.7 x 10 in (510.5 x 195.5 x 254 mm)
- Magnetic Pole Footprint: 492.75 mm x 97.6 mm
